项目item |
单位unit |
规格specification |
规格specification |
|
|
型 号 m o d e l |
|
5H-5(输送带款) (belt type) |
5H - 5(搅拢款) (agitation payment) |
|
|
结构形式structural style |
|
批式循环Batch cycle |
||
|
工作原理Working principle |
|
混流式Mixed flow type |
||
|
外形尺寸
overall dimension |
长length |
mm |
1800 |
1800 |
|
宽width |
mm |
1800 |
1800 |
|
|
高height |
mm |
6875 |
5900 |
|
|
机体重量(总重) |
kg |
1700 |
1650 |
|
|
最大容量Maximum capacity |
M3 |
9.5 |
9.5 |
|
|
批处理量(稻谷)Batch capacity (rice) |
Kg/批batch |
1500～5000 |
1500～5000 |
|
|
总功率Total power |
kW |
6.3 |
5.6 |
|
|
破碎率增值Increase in crushing rate |
% |
≤0.1 |
≤0.5 |
|
|
爆腰率增值Increase in burst waist |
% |
≤1 |
≤1 |
|
|
单位耗热量Unit heat consumption |
kJ/kg(H20) |
≤4500 |
≤4500 |
|
|
干燥后谷物含水率的不均匀度 Unevenness of moisture content of grain afterdrying |
% |
≤1.0 |
≤1.0 |
|
|
干燥能力Drying ability |
t ·%/h |
≥3.75 |
≥3.75 |
|
