项目item |
单位unit |
规格specification |
|
|
型号model |
|
5H-30 |
|
|
工作原理Working principle |
/ |
混流式Mixed flow type |
|
|
结构形式structural style |
|
批式循环Batch cycle |
|
|
外 形 尺 寸 overall dimension |
长length |
mm |
3096 |
|
宽width |
mm |
3096 |
|
|
高height |
mm |
9960 |
|
|
机体重量(总重)Body weight (total weight) |
Kg |
8500 |
|
|
处理量 Processing capacity |
稻谷(容重=560Kg/m3)Rice(unit weight=560kg/m3) |
Kg |
10000-32000 |
|
小麦(容重=680Kg/m3)Wheat (unit weight =680kg/m3) |
Kg |
12000-38400 |
|
|
总功率(不含热源)Total power (excluding heat source) |
KW |
19.8 |
|
|
破碎率增值Increase in crushing rate |
% |
≤0.3 |
|
|
爆腰率增值Increase in burst waist rate |
% |
≤2 |
|
|
干燥后谷物含水率的不均匀度Unevenness of moisture content of grain after drying |
% |
≤0.5 |
|
|
平均降水幅度Average precipitation range |
%/h |
0.5-1.2 |
|
|
配套电源Auxiliary power supply |
/ |
三相Three-phase380V 50HZ |
|
