项目item |
单位unit |
规格specification |
|||
|
规格型号Model No. |
|
5HL-10 |
5HL-15 |
5HL-20 |
|
|
工作原理Work Principle |
|
混流式Mixed flow type |
|||
|
结构形式Structure |
/ |
塔式Tower Type、间接加热Indirect Heating Batch Type |
|||
|
批式循环Mixed Air Circulation |
|||||
|
外形尺寸 Dimensions |
长Length |
mm |
2380 |
2380 |
2980 |
|
宽Width |
mm |
2080 |
2080 |
2380 |
|
|
高Height |
mm |
8638 |
11135 |
11165 |
|
|
机体重量Weight |
kg |
3100 |
3500 |
4100 |
|
|
最大容量Maximum Loading Capacity |
m³ |
23 |
32.5 |
44 |
|
|
总功率Work Voltage |
kw |
7.7 |
9.2 |
12.3 |
|
|
处理量Output |
Kg/批 Batch |
10000 |
15000 |
20000 |
|
|
破碎率增值Breakage Rate |
% |
≤0.5 |
|||
|
爆破率增值Increase in burst waist |
% |
≤2 |
|||
|
单位耗热量Heat Consumption |
% |
≤5800*1.4(8120) |
|||
|
干燥后谷物含水率不均度 The moisture content after drying |
% |
≤1.0 |
|||
|
干燥能力Drying Capacity |
T-%/H |
≥7.5 |
≥10.5 |
≥15.0 |
|
