项目Item |
单位Unit |
规格Specifications |
|
|
型号Model |
/ |
5HG-23 |
5HGS-50 |
|
结构形式Structural Style |
/ |
箱式Closed box type |
箱式Closed box type |
|
外形尺寸Dimension |
mm |
4838x2600x2350 |
9730x3850x4050 |
|
处理量(湿物料) Handling Capacity (Wet Material) |
kg/h |
≥20 |
≥40 |
|
总功率Total Power |
kw |
2.79 |
2.79 |
|
单位耗热量Unit Heat Consumption |
KJ/kg (H₂O) |
≤5800 |
≤5800 |
|
有效烘干容积Effective Drying Volume |
m |
23 |
40.4 |
|
总烘干面积Total Drying Area |
m² |
108 |
258 |
|
热风温度范围 Hot Air Temperature Range |
摄氏度 celsius |
室温-130(Indoor Temperature～130 degree) |
室温-130(Indoor Temperature～130 degree) |
|
温度/湿度控制方式 Temperature /Humidity Control Mode |
/ |
智能控制 Intelligent Control |
智能控制 Intelligent Control |
